Proximity Sensor

• Accuracy
• High

• Application
• Cylinder Position Sensing

• Cable Length
• 2 meter

• Features
• Strong resistance against vibration/shock, short-circuit protection, LED indicator

• Function
• Position Sensing

• IP Rating
• IP67

• Input
• DC 10-30V

• Interface
• Cable

• Material
• Plastic, Metal

• Measurement Range
• 3mm

• Mounting Type
• Clamp or Screw Mount

• Operating Temperature
• -25C to +70C

• Output
• PNP/NPN Open Collector

• Power Consumption
• 10 mA

• Product Type
• Magnetic Type Sensor

• Resolution
• 0.01 mm

• Response Time
• 1 ms

• Sensitivity
• High

• Sensor Type
• Magnetic

• Signal Type
• Digital

• Usage
• Industrial Automation

• Voltage
• 10-30V DC

• Weight
• 40g

• Wireless
• No

• Accuracy
• High detection accuracy

• Application
• Automation, conveyors, position detection

• Cable Length
• 2 m (standard)

• Features
• Compact size, high repeatability, dustproof

• Function
• Detects object presence or passage

• IP Rating
• IP64

• Input
• 5 to 24 V DC

• Interface
• Cable-connected

• Material
• Polycarbonate (main unit)

• Measurement Range
• Sensing distance: 6 mm

• Mounting Type
• Through-hole or surface mount

• Operating Temperature
• -25 to +55C (no freezing)

• Output
• NPN open-collector transistor

• Power Consumption
• 10 mA or less

• Product Type
• U-Shaped Micro Photoelectric Sensor

• Response Time
• 1 ms or less

• Sensitivity
• Pre-set (fixed for model)

• Sensor Type
• Photoelectric

• Signal Type
• Other, Digital (ON/OFF)

• Usage
• Object detection in automation equipment

• Voltage
• 5 to 24 V DC

• Weight
• Approx. 10 g

• Wireless
• No

• Accuracy
• High

• Application
• Position Sensing

• Cable Length
• 2 meters

• Features
• Short circuit protection, LED indicator

• Function
• Object Detection

• IP Rating
• IP67

• Input
• DC 12-24V

• Interface
• 3-wire DC

• Material
• PBT plastic

• Measurement Range
• 10 mm sensing distance

• Mounting Type
• Panel / Screw Mount

• Operating Temperature
• -25C to 70C

• Output
• NPN NO / PNP

• Power Consumption
• Max. 10mA

• Product Type
• Inductive Proximity Sensor

• Resolution
• Standard

• Response Time
• <2 ms

• Sensitivity
• Fixed

• Sensor Type
• Inductive

• Signal Type
• Digital

• Usage
• Industrial

• Voltage
• 12 V

• Weight
• Approx. 65g

• Wireless
• No

• Accuracy
• High precision

• Application
• Automation, robotics, conveyors, labeling machines

• Cable Length
• 2 meters

• Features
• Compact design, high reliability, fast response

• Function
• Through-beam detection

• IP Rating
• IP64

• Input
• 12-24 V DC

• Interface
• 3-wire connection

• Material
• Polycarbonate (housing)

• Measurement Range
• Slot width 3.6 mm

• Mounting Type
• Panel mount, M2 screws

• Operating Temperature
• -10C to +55C (no condensation or icing)

• Output
• NPN open collector

• Power Consumption
• 10 mA or less

• Product Type
• U-Shaped Micro Photoelectric Sensor

• Resolution
• Detects min. object size of 0.2 mm

• Response Time
• 0.5 ms or less

• Sensitivity
• Adjustable (by distance of insertion)

• Sensor Type
• Photoelectric sensor

• Signal Type
• Digital

• Usage
• Object detection, position sensing

• Voltage
• 12 to 24 V DC, ripple P-P 10% or less

• Weight
• Approximately 4.5g

• Wireless
• No

• Accuracy
• High

• Application
• Position & Presence Sensing

• Cable Length
• 2 m

• Features
• Short-circuit Protection

• Function
• Object Detection

• IP Rating
• IP67

• Input
• DC

• Interface
• 3-wire DC

• Material
• Nickel Plated Brass

• Measurement Range
• 10 mm Sensing Distance

• Mounting Type
• Flush Mount

• Operating Temperature
• -25C to +70C

• Output
• PNP Normally Open (NO)

• Power Consumption
• 15 mA

• Product Type
• Inductive Proximity Sensor

• Response Time
• 2 ms

• Sensitivity
• Fixed

• Sensor Type
• Inductive

• Signal Type
• Other, Discrete

• Usage
• Industrial Automation

• Voltage
• 10-30 VDC

• Weight
• Approx. 85 g

• Wireless
• No

• Material
• Stainless Steel

• Measurement Range
• 20 mm

• Mounting Type
• Panel Mount

• Product Type
• Proximity Sensor

• Usage
• For Industrial

• Application
• Industrial

• Material
• Stainless Steel

• Measurement Range
• 15 mm

• Mounting Type
• Flush mount

• Operating Temperature
• -25 to 70C

• Product Type
• Proximity Sensor

• Response Time
• <1 ms

• Sensor Type
• Proximity Sensor

• Usage
• for Industrial

• Measurement Range
• 100 mm

• Output
• NPN

• Product Type
• Diffuse Photoelectric Sensor

• Sensor Type
• Diffuse

• Voltage
• 12/24 VDC

• Accuracy
• High

• Application
• Position Sensing, Metal Detection

• Cable Length
• 2 m

• Features
• Shielded, Short-Circuit Protection

• Function
• Object Detection

• IP Rating
• IP67

• Input
• DC

• Interface
• 2-Wire DC

• Material
• Nickel-Plated Brass

• Measurement Range
• 0-7 mm

• Mounting Type
• M18 Threaded

• Operating Temperature
• -25C to +70C

• Output
• NO (Normally Open)

• Power Consumption
• Max 10 mA

• Product Type
• Proximity Sensor

• Resolution
• Standard

• Response Time
• <1 ms

• Sensitivity
• Fixed

• Sensor Type
• Inductive

• Signal Type
• Other, PNP

• Usage
• Industrial Automation

• Voltage
• 12-24V DC

• Weight
• Approx. 70 g

• Wireless
• No

• Accuracy
• High repeat accuracy ( 0.1 mm)

• Application
• Pneumatic actuators, automation industry

• Cable Length
• 2.5 meters

• Features
• LED switching status indicator, resistant to shock and vibration

• Function
• Electromagnetic sensing of cylinder piston position

• IP Rating
• IP65 / IP68

• Input
• 24V DC

• Interface
• 3-wire, open cable end

• Material
• Plastic Housing

• Measurement Range
• Detects magnetic field of integrated piston magnet

• Mounting Type
• Flush (groove) mount; fits 8 mm T-slot cylinders

• Operating Temperature
• -40C to +70C

• Output
• PNP, normally open (NO)

• Power Consumption
• 10 mA

• Product Type
• Proximity Sensor

• Resolution
• Very high, suitable for precise end-position sensing

• Response Time
• < 1 ms

• Sensitivity
• Detects magnetic field (> 1.3 mT at sensor)

• Sensor Type
• Magnetic proximity switch

• Signal Type
• Digital

• Usage
• Position detection in pneumatic cylinders

• Voltage
• 24V DC (Operating voltage range 10-30V DC)

• Weight
• approx. 21 g (incl. 2.5 m cable)

• Wireless
• No
