Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor

Name: Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor
Brand: Electro Automation Industries
Price: 750 INR
Availability: InStock

Price 750 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor Specification

Feature
Flush mountable

Shape
Cylindrical

Connector Type
M12 male

Mounting Type
Threaded barrel

Surface Finish
Nickel-plated

Humidity %
35-95% RH

Insulation Material
Plastic/Polyester

Operating Temperature
-25C to +70C

IP Rating
IP67

Overheating Protection
YES

Efficiency
High reliability

Product Type
Inductive Proximity Sensor

Application
Industrial Automation

Protection Level
Short-circuit protection

Frequency (MHz)
0.05

Rated Voltage
10-30 V DC

Energy Consumption
Max. 1.5 W

Output Type
PNP NO

Color
Metallic Silver

Dimension (L*W*H)
M18 x 50 mm

Weight
Approx. 50 g

Input Voltage
10-30 V DC

Phase
Single Phase

Size
M18

No Of Poles
3

Connection Type
Connector, 4-pin

Material
Nickel-plated brass

Sensing distance
12 mm

Housing diameter
18 mm

Reverse polarity protection
Yes

Output current
Max 200 mA

Model
NBN12-18GM50-E2-V1

Status indicator
LED

Switching frequency
500 Hz

Sensing face material
Plastic

Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor

Experience exceptional performance with the Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor! Unlock outstanding reliability for your automation system with this robust, affordable sensor engineered for precision. Grab this splendid cylindrical sensor-crafted from nickel-plated brass for durability-offering a 12 mm sensing distance and supporting up to 200 mA output current. Equipped with short-circuit and reverse polarity protection, IP67 rating, and flush mountable design, the NBN12-18GM50-E2-V1 is ready for demanding industrial needs. Its high-quality build ensures longevity while the advanced features simplify installation and maintenance. Order today to unlock heightened efficiency!

Comprehensive Usage and Application Details

The Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor is straightforward to install using its threaded barrel mounting. It is ideally suitable for industrial automation processes, particularly where reliable object detection and position sensing are required. Primarily used by automation engineers, technicians, and maintenance professionals in manufacturing and process industries, the sensor ensures dependable operation. Connect it easily via the M12 male connector and benefit from the flush mountable feature for a compact setup.

Sample Policy, Delivery, and Certifications

Our sample policy allows you to review the Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor before committing to a larger order-contact us for a list price and sample terms. Shipped goods are dispatched promptly, with typical delivery time spanning 5 to 10 business days after confirmation. All shipped units are certified for exceptional quality and compliance with international industry standards, ensuring that you receive only reliable and fully vetted products for your enterprise.

FAQ's of Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor:

Q: How do I install the Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor?

A: The sensor can be effortlessly installed using its threaded barrel design. Simply use the M18 x 50 mm body to mount it securely and connect the 4-pin M12 male connector to your system.

Q: What are the main benefits of using this sensor for industrial automation?

A: This sensor offers splendid reliability, outstanding durability with nickel-plated brass housing, short-circuit and overheating protection, and a compact, flush mountable design. Its high switching frequency and clear LED status indicator maximize efficiency in demanding industrial environments.

Q: Where is the Pepperl Fuchs NBN12-18GM50-E2-V1 Sensor typically used?

A: It is extensively used in factories, process automation, and manufacturing units for precise detection tasks, owing to its IP67 protection level and robust construction.

Q: What is the process for obtaining a sample of this sensor?

A: To obtain a sample, contact our sales team with your request. Once terms are agreed, the goods will be shipped as per our sample policy and usual delivery timeline.

Q: How does the LED status indicator assist in usage?

A: The integrated LED status indicator provides immediate feedback on the sensor's operational status, allowing users to quickly confirm proper functioning or identify potential issues during setup and routine checks.
