TSFA TS6.5-1.5P1 DC 3 Wire Sensors

Name: TSFA TS6.5-1.5P1 DC 3 Wire Sensors
Brand: Electro Automation Industries
Price: 250 INR
Availability: InStock

Price 250 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

TSFA TS6.5-1.5P1 DC 3 Wire Sensors Specification

Mounting Type
Flush Mount

Power Factor
0.95

Efficiency
High

Surface Finish
Nickel Plated

Connector Type
Cable

Feature
High Sensitivity, Compact Design

Overheating Protection
YES

Shape
Cylindrical

Operating Temperature
-25C to +70C

IP Rating
IP67

Humidity %
95% RH

Insulation Material
ABS

Product Type
Proximity Sensor

Application
Automation, Industrial Machinery

Protection Level
Short-circuit and Overload Protection

Frequency (MHz)
50/60 Hz

Rated Voltage
10-30 V DC

Energy Consumption
10 mA

Output Type
PNP Normally Open (NO)

Color
Black and Silver

Dimension (L*W*H)
M6 x 32 mm

Weight
25 g

Input Voltage
10-30 V DC

Phase
Single Phase

Size
6.5 mm Diameter

Connection Type
3-Wire

No Of Poles
3

Material
ABS Plastic, Metal

Withstand Voltage
1000 V AC for 1 min

Reverse Polarity Protection
Yes

Switching Frequency
1 kHz

Voltage Drop
1.5V (at max load)

Max Load Current
200 mA

Current Consumption
<10 mA (No Load)

Housing Material
Nickel-Plated Brass

Sensing Distance
1.5 mm (Flush)

Indicator
LED Output Indicator

Storage Temperature
-40C to +85C

Response Time
1 ms

Repeat Accuracy
5%

TSFA TS6.5-1.5P1 DC 3 Wire Sensors Trade Information

Minimum Order Quantity
50 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About TSFA TS6.5-1.5P1 DC 3 Wire Sensors

Select the TSFA TS6.5-1.5P1 DC 3 Wire Sensor for splendid performance in automation and industrial machinery. This marvelously compact, cylindrical device measures just 6.5 mm in diameter, embodying scarce precision with a sensing distance of 1.5 mm (flush) and rapid 1 ms response time. Constructed from venerable nickel-plated brass and ABS, its robust build and IP67 rating offer superior protection. Enhanced with short-circuit, overload, and reverse polarity safeguards, plus an LED output indicator, this sensor ensures reliable access to high-sensitivity, efficient, and steadfast industrial solutions.

Exclusive Features and Distinct Advantages

The TSFA TS6.5-1.5P1 sensor stands out with its high sensitivity, rapid response (1 ms), and compact, flush-mount design. Its robust housing of nickel-plated brass, alongside IP67 protection, ensures marvelous durability. With short-circuit, overload, and reverse polarity safeguards, it offers splendid safety. The 1 kHz switching frequency and energy-efficient operation (<10 mA consumption) make it ideal for automation. Clearly visible LED output indicators and reliable PNP NO output add to its advantage, ensuring precise performance in demanding environments.

Sample Policy, Supply Capacity, and Certifications

Expenditure considerations are minimized as sample policies are customer-friendly and samples can be handed over swiftly. With a strong domestic market presence, the supply ability meets substantial industrial requirements reliably across India. The sensor upholds venerable certifications, attesting its compliance with global quality benchmarks. Whether handling initial inquiries or large orders, the process ensures all sensors meet rigorous standards, guaranteeing buyers obtain authenticated, high-performance components tailored to their unique applications.

FAQ's of TSFA TS6.5-1.5P1 DC 3 Wire Sensors:

Q: How does the TSFA TS6.5-1.5P1 sensor benefit industrial automation?

A: The sensor delivers high-speed response, accurate detection, and durable protection, making it ideal for automation tasks that demand precision and reliability.

Q: What are the main features that set this DC 3 Wire Sensor apart from others?

A: Key features include its fast 1 ms response time, 1 kHz switching frequency, IP67 rating, high sensitivity, and comprehensive protection functions like overload and reverse polarity protection.

Q: Where can the TSFA TS6.5-1.5P1 sensor be used?

A: It can be utilized across industrial machinery, automation setups, assembly lines, and harsh environments requiring robust, dependable proximity sensing.

Q: What is the installation process for this sensor?

A: Installation is straightforward, involving flush-mounting the sensor and connecting its 3-wire cable, ensuring the operating voltage is within 10-30 V DC.

Q: When is the sensor best suited for replacement or upgrading existing systems?

A: It's ideal when high sensitivity, rapid response, and advanced protection measures are required to enhance efficiency, safety, or detection precision in current systems.

Q: How is the supply and sample policy managed for domestic customers?

A: Samples can be delivered efficiently with minimal expenditure, and the company's strong supply network ensures seamless access to both small and large orders within the domestic market.
