E6C2-CWZ5B 360PPR Omron Rotary Encoder

E6C2-CWZ5B 360PPR Omron Rotary Encoder About

E6C2-CWZ5B 360PPR Omron Rotary Encoder Specifications

• Brand: Omron
• Model: E6C2-CWZ5B
• Encoder Type: Incremental Rotary Encoder
• Resolution: 360 Pulses Per Revolution PPR
• Output Type: PNP Open Collector
• Output Phases: A B Z
• Power Supply Voltage: 12 to 24 VDC
• Supply Voltage Tolerance: 12 VDC Minus 10 Percent to 24 VDC Plus 15 Percent
• Current Consumption: 100 mA Maximum
• Output Current: 35 mA Maximum
• Residual Output Voltage: 0.4 V Maximum
• Response Frequency: 100 kHz Maximum
• Starting Torque: 9.8 mN m Maximum
• Maximum Rotational Speed: 6000 rpm
• Shaft Diameter: 6 mm
• Encoder Body Diameter: 50 mm
• Shaft Type: Solid Shaft
• Connection Method: Pre Wired Cable
• Cable Length: 2 m
• Degree of Protection: IP50
• Operating Temperature: Minus 10 C to Plus 70 C
• Storage Temperature: Minus 25 C to Plus 85 C
• Operating Humidity: 35 Percent to 85 Percent RH
• Insulation Resistance: 100 M Minimum at 500 VDC
• Dielectric Strength: 1000 VAC for 1 Minute
• Vibration Resistance: 10 to 55 Hz Double Amplitude 1.5 mm
• Shock Resistance: 500 m s
• Housing Material: Aluminum
